Chevrolet Camaro IV (1992-1998) passenger power seat switch Wiring diagram
This page shows the only wiring diagram for the component.passenger power seat switch, which is found in the car Chevrolet Camaro IV (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger power seat switch (1 of 1)
1995 VFTC
AIR IN/OUT
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CUTOUT RELAY
DEFLATE
DEFLATE INFLATE
DEFLATE RELAY
DK BLU WIRE
DRIVER POWER SEAT SWITCH
DRIVER SEAT ASSEMBLY
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES DEFOG/SEATS CIRCUIT BREAKER 12
I/P FUSE BLOCK
INFLATE
INFLATE RELAY
LATERAL
LATERAL BLADDER
LUMBAR
LUMBAR BLADDER
LUMBAR BLADDER LATERAL BLADDER
ORG/ WIRE
PASSENGER POWER SEAT SWITCH
PASSENGER SEAT ASSEMBLY
POWER SEAT CONTROL MODULE
PPL
PRESSURE SWITCH
PUMP ASSEMBLY
SOLENOID VALVE ASSEMBLY
WHT WIRE
Go to component -> Lumbar circuit -> PASSENGER POWER SEAT SWITCH
