Chevrolet Camaro IV (1992-1998) mirror position switch Wiring diagram
This page shows the only wiring diagram for the component.mirror position switch, which is found in the car Chevrolet Camaro IV (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror position switch (1 of 1)
1995 VFTC
BLK WIRE
BLU WIRE
BRN/WHT WIRE
DOWN UP
GRY WIRE
HOT AT ALL TIMES PWR ACCY FUSE 7
I/P FUSE BLOCK
LEFT OUT- SIDE MIRROR
LEFT/RIGHT MOTOR
LT BLU WIRE
MIRROR POSITION SWITCH
MIRROR SELECT SWITCH
NCA WIRE
ORG/ WIRE
POWER MIRROR SWITCH
RED WIRE
RED/WHT WIRE
RIGHT LEFT
RIGHT OUT- SIDE MIRROR
UP/DOWN MOTOR
WHT WIRE
YEL WIRE
