Chevrolet Camaro IV (1992-1998) left rear tail/ stop/ turn lights Wiring diagram
This page shows the only wiring diagram for the component.left rear tail/ stop/ turn lights, which is found in the car Chevrolet Camaro IV (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear tail/ stop/ turn lights (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (MOUNTED TO HVAC MODULE, RIGHT SIDE OF I/P)
BRAKE SWITCH ASSEMBLY (ON BRAKE PEDAL BRACKET)
BRN WIRE
CONVENIENCE CENTER (LEFT OF STEERING COLUMN)
CRUISE CONTROL SYSTEM
DK BLU WIRE
DK GRN WIRE
FUSE 1
FUSE 2
GRN WIRE
HAZARD
HAZARD FLASHER
HEAD LIGHT SWITCH
HEAD OFF PARK
HEADLIGHTS SYSTEM
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
HOT IN RUN
I/P FUSE BLOCK
INSTRUMENT CLUSTER
LEFT FRONT PARK/ TURN LIGHT LEFT FRONT MARKER LIGHT
LEFT REAR MARKER LIGHT
LEFT REAR TAIL/ STOP/ TURN LIGHTS
LEFT TAIL LIGHT
LEFT TURN IND
LICENSE LIGHT
LT BLU WIRE
NORMAL
OPTIONAL
ORG/ WIRE
PARK LAMP RELAY (TOP CENTER OF I/P)
PONT ONLY
PPL
PWR ACCY FUSE 7
RIGHT FRONT MARKER LIGHT
RIGHT FRONT PARK/ TURN LIGHT
RIGHT REAR MARKER LIGHT RIGHT REAR TAIL/ STOP/ TURN LIGHTS
RIGHT TAIL LIGHT
RIGHT TURN IND
SOUND SYSTEMS
STOP/ HAZARD
TAIL LTS FUSE 5
TURN B/U
TURN FLASHER
TURN LEFT
TURN RIGHT
TURN/ HAZARD SWITCH ASSEMBLY
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, without drl -> LEFT REAR TAIL/ STOP/ TURN LIGHTS
