Chevrolet Camaro IV (1992-1998) hot in accy, run or rap Wiring diagram
This page shows the only wiring diagram for the component.hot in accy, run or rap, which is found in the car Chevrolet Camaro IV (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in accy, run or rap (1 of 1)
1995 VFTC
ANTENNA
ANTENNA COAXIAL
ANTENNA RELAY
BLK WIRE
CABLE)
DOWN
DOWN SWITCH DOWN
DOWN UP
HOT AT ALL TIMES
HOT IN ACCY, RUN OR RAP
I/P FUSE BLOCK
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER ANTENNA MOTOR
RADIO
RADIO ACCY FUSE 4 20 AMP
RADIO FUSE 17 15 AMP
RADIO POWER ANTENNA (BEHIND RIGHT QUARTER INTERIOR TRIM PANEL)
SOLID STATE
UP UP SWITCH
YEL WIRE
Go to component -> Power antenna circuit -> HOT IN ACCY, RUN OR RAP
