Chevrolet Camaro IV (1992-1998) headlights system 225 728 640 starting/charging system Wiring diagram

1174 39 PNK WIRE 2 1 31 47 PPL VSS LO INPUT ABS FAIL ABS INOP IND. AIR BAG IND ANTI-THEFT SYSTEM ASR IND. CTRL ASR OFF IND. BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (RIGHT SIDE OF I/P) BRAKE COMBO VALVE BRAKE IND BRAKE IND. CTRL BRN WIRE BRN/WHT WIRE CHECK GAGES IND. CLUSTER ILLUM. COOLANT TEMP GAGE DAYTIME RUNNING LIGHTS MODULE (LEFT OF I/P COMPT) DK BLU WIRE DK BLU/WHT WIRE DK CRUISE CONTROL SYSTEM DK GRN WIRE DK GRN/WHT WIRE ELECTRONIC BRAKE CONTROL MODULE OR ELECTRONIC BRAKE/TRACTION CONTROL MODULE ELECTRONIC IGNITION CONTROL MODULE (LEFT FRONT OF ENGINE) ENGINE SPEED ENGINE COOLANT LEVEL SENSOR (TOP RIGHT SIDE OF RADIATOR) ENGINE COOLANT TEMPERATURE GAGE SENSOR (FRONT OF ENGINE) ENGINE SPEED FASTEN SEAT BELT IND FUEL GAGE FUEL GAGE SENDER FUEL TANK UNIT GAGES FUSE 9 GEAR GEN SNS GEAR IND GND BAT (+) GRN WIRE GRY WIRE HEADLIGHTS SYSTEM 225 728 640 STARTING/CHARGING SYSTEM HI-BEAM IND HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START HYDRAULIC MODULATOR ASSEMBLY I/P FUSE BLOCK (LEFT SIDE OF I/P) IGN OIL CLNT INSTRUMENT CLUSTER LEFT TURN IND LOW COOLANT IND LOW COOLANT LATCHING IND CTRL LOW OIL LOW OIL IND. LOW TRAC IND LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE NCA WIRE ODO- METER OIL LEVEL SENSOR (IN OIL PAN) OIL PRESS GAGE OIL PRESSURE SENSOR ORG/ WIRE PARK BRAKE SWITCH PNK WIRE PPL PPL/WHT WIRE PWR ACCY FUSE 7 RED WIRE RIGHT TURN IND SECURITY IND SERVICE ENGINE SOON IND (MIL) SKIP SHIFT IND CTRL SKIP SHIFT IND. ASR OFF/ SOLID STATE SPEEDO- METER SOLID STATE TACHO- METER START IND TAN WIRE TAN/WHT WIRE TRUNK, TAILGATE, FUEL DOOR SYSTEM (HATCH RELEASE RELAY) VOLT- METER VSS HI INPUT VSS OUTPUT 4000 P/M W/ M/T W/ TRACTION CONTROL W/ TRACTION CONTROL LT W/DRL W/O DRL WARNING SYSTEM (W/O DRL) (W/DRL) ENGINE CONTROLS SYSTEM WHT WIRE YEL WIRE YEL/BLK WIRE
