Chevrolet Camaro IV (1992-1998) front height motor Wiring diagram
This page shows the only wiring diagram for the component.front height motor, which is found in the car Chevrolet Camaro IV (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front height motor (1 of 1)
1995 VFTC
BACK
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DOWN DOWN
DRIVER SEAT ASSEMBLY
ENTIRE SEAT
ENTIRE SEAT DOWN
FOR- WARD
FORWARD/ BACK MOTOR
FRONT HEIGHT MOTOR
HOT AT ALL TIMES DEFOG/SEATS CIRCUIT BREAKER 12
I/P FUSE BLOCK
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
POWER SEAT ACTUATOR ASSEMBLY
POWER SEAT SWITCH
REAR HEIGHT
REAR HEIGHT FRONT HEIGHT FRONT HEIGHT
REAR HEIGHT MOTOR
TAN WIRE
YEL WIRE
Go to component -> 6-way power seat circuit -> FRONT HEIGHT MOTOR
