Chevrolet Camaro IV (1992-1998) belt indic ctrl Wiring diagram
This page shows the only wiring diagram for the component.belt indic ctrl, which is found in the car Chevrolet Camaro IV (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram belt indic ctrl (1 of 1)
BATTERY (B+)
BELT INDIC CTRL
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (ABOVE RIGHT I/P INSULATOR PANEL)
BRN WIRE
FASTEN SEAT BELT INDIC
GAGES FUSE 9
GROUND
GRY WIRE
GRY/BLK WIRE
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES I/P FUSE BLOCK COURTESY FUSE 8
HOT IN RUN, BULB TEST OR START HOT AT ALL TIMES
IGNITION KEY WARNING SWITCH (INSIDE STEERING COLUMN)
INSTRUMENT CLUSTER
KEY-IN-IGN IN
LEFT DOOR JAMB SWITCH
LFT DOOR SW IN
LIGHTS ON IN
LT GRN WIRE
NCA WIRE
OFF PARK
ORG/ WIRE
PNK IGNITION POWER WIRE
PNK WIRE
PPL/WHT WIRE
RIGHT DOOR JAMB SWITCH
RT DOOR SW IN
SEAT BELT SWITCH (SEAT BELT BUCKLE ASSY)
SEAT BLT SW IN
SUPPLEMENTAL RESTRAINTS SYSTEM
Go to component -> Warning system circuits -> BELT INDIC CTRL
