Chevrolet Camaro IV (1992-1998) 2 3 lt frt spkr front spkrs wiring diagram
This page shows the only wiring diagram for the component.2 3 lt frt spkr front spkrs, which is found in the car Chevrolet Camaro IV (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
2 3 lt frt spkr front spkrs wiring diagram (1 of 1)
19 20 REAR SPKRS LT REAR SPKR
2 3 LT FRT SPKR FRONT SPKRS
ANTENNA
ANTENNA INPUT
AUD - L AUD + LR - LR + SHIELD
BARE
BARE GROUND SHIELDS RT REAR SPKR
BARE SHIELD RR + RR - R AUD +
BLK WIRE
BLU WIRE
BOSE RELAY (BELOW CENTER A/C DUCT)
BRN WIRE
COAXIAL CABLE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK LT
GRN WIRE
GRN/WHT WIRE
GROUND
GROUND POWER
GROUND SHIELDS
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC, RUN OR W/ RETAINED ACCESSORY POWER
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT FRONT AMPLIFIER/ SPEAKER UNIT
LEFT REAR SUBWOOFER SPEAKER
LT BLU/BLK WIRE
LT DK
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
ORG/ WIRE
PNK 8 9 10 WIRE
PNK WIRE
POWER AUD + AUD -
PWR ACCY FUSE 7
RADIO
RADIO ACCY FUSE 4
RADIO FUSE 17
REAR AMPLIFIER/ SPEAKER UNIT
RIGHT FRONT AMPLIFIER/ SPEAKER UNIT
RIGHT REAR SUBWOOFER SPEAKER
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Radio circuits, with bose system -> 2 3 LT FRT SPKR FRONT SPKRS
