Chevrolet Camaro IV (1992-1998) 157 624 28 interior lights system anti-theft system horns system Wiring diagram

157 624 28 INTERIOR LIGHTS SYSTEM ANTI-THEFT SYSTEM HORNS SYSTEM ACCY ANTI-THEFT SYSTEM ANTI-THEFT SYSTEM ENGINE CONTROLS SYSTEM BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (MOUNTED ON HVAC MODULE, ABOVE RIGHT I/P INSULATOR PANEL) BRN WIRE BULB TEST COURTESY FUSE 8 DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DOOR LOCKS SYSTEM FASTEN SEAT BELT INDIC LAMP FUSIBLE LINK E (16 GA- GAUGES FUSE 9 GROUND PASS-KEY RESISTOR INPUT GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN ACC, RUN OR W/ RAP ENERGIZED HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK IGNITION SWITCH INTERIOR LAMPS COMMAND PARK LAMP RELAY CTRL HORN RELAY CTRL LOCK OFF LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL/WHT WIRE RADIO FUSE 17 RED WIRE RED/BLK WIRE RUN WIRE TAN WIRE WARNING SYSTEMS WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
