Chevrolet Cab & Chassis Silverado 3500 (2004-2007) ctrl voltage class 2 Wiring diagram
This page shows the only wiring diagram for the component.ctrl voltage class 2, which is found in the car Chevrolet Cab & Chassis Silverado 3500 (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ctrl voltage class 2 (1 of 1)
A/T SHIFT LOCK CONTROL SOLENOID (ON STEERING COLUMN)
ALLISON TRANS
B/U LP FUSE
BLK WIRE
BODY CONTROL MODULE (BELOW STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
CTRL VOLTAGE CLASS 2
DIESEL
DK GRN WIRE
ENGINE CONTROL MODULE (LEFT FRONT OF ENG COMPT)
EXCEPT ALLISON TRANS
FUSE
GASOLINE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH)
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
PARK/ NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANS.)
PNK WIRE
POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENG COMPT)
STOPLAMP SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) BTSI FUSE
WHT WIRE
Go to component -> Shift interlock circuit -> CTRL VOLTAGE CLASS 2
