Chevrolet Cab & Chassis Silverado 3500 (2004-2007) 35 18 22 cpp sw set/coast sw resume/accel sw Wiring diagram
This page shows the only wiring diagram for the component.35 18 22 cpp sw set/coast sw resume/accel sw, which is found in the car Chevrolet Cab & Chassis Silverado 3500 (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 35 18 22 cpp sw set/coast sw resume/accel sw (1 of 1)
16 59 CRUISE ON INPUT CRUISE RELEASE SW PPL
20 50 VSS LOW VSS SIG
35 18 22 CPP SW SET/COAST SW RESUME/ACCEL SW
BRAKE FUSE
BRN WIRE
CLASS 2 DATA
CLUTCH PEDAL POSITION SWITCH (TOP OF CLUTCH PEDAL)
COMPUTER DATA LINES SYSTEM
CRUISE FUSE
CRUISE IND
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT IN RUN
I/P RELAY BLOCK (LEFT OF STEERING COLUMN)
IGN
INSTRUMENT PANEL CLUSTER
LEFT I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH)
LT GRN/BLK WIRE
NCA WIRE
OF TRANSFER CASE)
OF TRANSMISSION)
OFF
ON OFF
PPL
PPL/WHT WIRE
RADIO
REAR WHEEL STEERING CONTROL MODULE (IF EQUIPPED) (AT LEFT REAR OF VEHICLE)
RESUME/ ACCEL CRUISE CONTROL ON/OFF SWITCH
RESUME/ACCEL
SERIAL DATA
SET/ COAST
STOPLAMP SWITCH (TOP OF BRAKE PEDAL)
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK
VEHICLE SPEED SENSOR (VSS)
VSS HIGH
VSS SIG
WHT WIRE
Go to component -> 6.6l vin 1, cruise control circuit -> 35 18 22 CPP SW SET/COAST SW RESUME/ACCEL SW
