Horn circuit for Chevrolet Cab & Chassis Silverado 3500 HD (2008-2011)
Horn circuit
BLK WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
DK GRN WIRE
GROUND DISTRIBUTION SYSTEM
HORN (GAS) FUSE 29 (DIESEL) FUSE 26
HORN PCB RELAY
HORN RELAY CTRL
HORN SWITCH
HOT AT ALL TIMES UNDERHOOD FUSE HOLDER (ON POSITIVE BATTERY TERMINAL)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (BEHIND STEERING WHEEL)
LEFT HORN (LOWER LEFT FRONT OF VEHICLE)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RIGHT HORN (LOWER RIGHT FRONT OF VEHICLE)
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/ HIGH NOTE DUAL HORN, COMFORT, DECOR LEVEL 3 CONVENIENCE PACKAGE
W/ HORN/SIREN CIRCUIT WIRING PROVISIONS
W/ STEERING WHEEL HEATER, ACCESSORY STEERING CONTROL, AUTOMATIC CRUISE CONTROL
W/O STEERING WHEEL HEATER
