Chevrolet Cab & Chassis Silverado 3500 HD (2008-2011) wiper speed pcb relay Wiring diagram

15 7 WASHER RLY CTRL MTR PARK SW SIG 24 9 8 5 PNK WASHER SW SIG WIPER SW LO SIG LOW REF WIPER SW HI SIG WIRE BAT POS VOLT BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DK GRN WIRE DRIVER INFORMATION CENTER (DIC) FRONT WASHER DIODE FRT WASH FUSE 7 (EXCEPT 6.6L) FRT WASH PCB RELAY FRT WPR FUSE 36 (EXCEPT 6.6L) WPR FUSE 33 (6.6L) FUSE 5 (6.6L) GROUND DISTRIBUTION SYSTEM GRY WIRE HI LO HI LO OFF INT HOT AT ALL TIMES I/P FUSE BLOCK (LEFT SIDE OF DASH, INSTRUMENT PANEL CLUSTER (IPC) LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH) LOW WASHER FLUID IND SERIAL CTRL DATA LOGIC LT BLU WIRE LT GRN WIRE MIST MIST OFF INT WIPER SWITCH ORG/ WIRE PNK WIRE PPL RED/WHT WIRE RT STOP TRN FUSE 8 SERIAL DATA TAN WIRE TAN/BLK WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WASHER SWITCH WINDSHIELD WASHER FLUID LEVEL SWITCH (BOTTOM OF WASHER FLUID RESERVOIR) WINDSHIELD WASHER FLUID PUMP (BOTTOM OF WASHER FLUID RESERVOIR) WINDSHIELD WIPER MOTOR (UNDER LEFT SIDE OF WINDSHIELD COWL) WINSHIELD WIPER SW HI SIG WIPER CONTROL PCB RELAY WIPER HIGH SPEED DIODE WIPER LOW SPEED DIODE WIPER SPEED PCB RELAY WNDSHLD WIPER SW SIG 2 YEL WIRE
