Chevrolet Cab & Chassis Silverado 3500 HD (2008-2011) gmlan serial hi spd Wiring diagram

10 11 HIGH SPEED BUS (+) HIGH SPEED BUS (-) AUTOMATIC TRANSMISSION (6.6L) AUTOMATIC TRANSMISSION FLUID PRESSURE (TFP) MANUAL VALVE POSITION SWITCH BACKUP ALARM BACKUP LAMP (LEFT) BACKUP LAMP- RIGHT BCK/UP LAMP PCB RELAY BCK/UP RLY LOW SPEED SERIAL DATA BCK/UP SIG BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DATA BUS - DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE EXCEPT 6.6L 6.6L GMLAN SERIAL HI SPD GRD GRN WIRE GRY WIRE HIGH SPEED BUS + HIGH SPEED BUS - HIGH SPEED GMLAN SERIAL DATA BUS + INSIDE REARVIEW MIRROR (ISRVM) LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH) LT GRN WIRE LT GRN/BLK WIRE MJR NCA WIRE ORG/ WIRE PARK/NEUTRAL POSITION (PNP) SWITCH (ON LEFT REAR SIDE OF TRANSMISSION) PNK WIRE POWER DISTRIBUTION SYSTEM REAR LAMPS JUNCTION BLOCK (INSIDE OF LEFT REAR FRAME RAIL) REAR VIEW CAMERA IMAGE DISPLAY MODULE (IF EQUIPPED) REARVIEW CAMERA (LEFT OF TAILGATE HANDLE) RED WIRE RED/BLK WIRE SW SIG 4 SW SIG A SW SIG B SW SIG C TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TRAILER TOW CIRCUIT TRANS RANGE SIG A TRANS RANGE SIG B TRANS RANGE SIG C TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION CONTROL MODULE (TCM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD) TRANSMISSION RANGE SWITCH SIGNAL A TRANSMISSION RANGE SWITCH SIGNAL B TRANSMISSION RANGE SWITCH SIGNAL C TRLR BCK/UP FUSE 10 FUSE 9 UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VEH BCK/UP FUSE 15 FUSE 14 W/ COMFORT, DECOR LEVEL 3 CONVENIENCE PACKAGE W/ SPO REARVIEW CAMERA WHT WIRE YEL WIRE YEL/BLK WIRE
