Chevrolet Cab & Chassis Silverado 3500 HD (2008-2011) app sen 2 sig low ref ppl Wiring diagram

44 57 15 49 29 SER DATA BUS- SER DATA BUS+ 7 20 2 4 6 MOTOR CTRL 2 MOTOR CTRL-1 83 77 STOP LAMP SW SIG BATT + ACCELERATOR PEDAL POSITION (APP) SENSOR (ABOVE ACCELERATOR PEDAL) APP SEN 1 SIG LOW REF APP SEN 2 SIG LOW REF PPL BATT + BLK/WHT WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL IND DIMMING SIG CRUISE CONTROL SWITCH SIGNAL CRUISE IND CRUISE SWITCH DK BLU WIRE DK GRN WIRE ECM BATT FUSE 11 ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, NEAR FAN SHROUD) GMLAN DATA BUS- GRN/WHT WIRE GROUND GROUND GROUND GROUND GRY WIRE HI SPD GMLAN SER DATA BUS- HOT AT ALL TIMES HOT AT ALL TIMES I/P FUSE BLOCK (LEFT SIDE OF DASH) DIM FUSE HOT W/ RUN/CRNK RELAY ENERGIZED INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (BEHIND STEERING WHEEL) INSTRUMENT PANEL CLUSTER (IPC) IPC FUSE 43 LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH) LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY LOGIC LT BLU WIRE LT BLU/WHT WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE MISC IGN FUSE 40 ORG/WHT WIRE PNK STEERING WHEEL CNTRL SUP VOLT WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL BRAKE SW SIG PPL/WHT WIRE RED/WHT WIRE RES+ SER DATA SET- SOUND SYSTEMS STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) TAN WIRE TAN/BLK WIRE TP SENS SIG LOW REF TRANSMISSION CONTROL MODULE (TCM) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (REAR OF TRANSMISSION) VSS HI SIG VSS LO SIG W/ TWO SPEED PUSH BUTTON, ELECTRIC SHIFT CONTROL TRANSFER CASE W/O TWO SPEED PUSH BUTTON, ELECTRIC SHIFT CONTROL TRANSFER CASE WHT/BLK WIRE YEL WIRE
