Chevrolet Cab & Chassis Silverado 3500 HD (2008-2011) accessory voltage window down window up Wiring diagram

ACCESSORY VOLTAGE ACCESSORY VOLTAGE WINDOW DOWN WINDOW UP B+ VOLT BLK WIRE BODY CONTROL MODULE (BCM) (LOWER LEFT SIDE OF DASH) BRN WIRE BRN/WHT WIRE DK BLU WIRE DK GRN WIRE DRIVER WINDOW MOTOR (INSIDE DRIVER'S DOOR) DRIVER WINDOW SWITCH GROUND HOT AT ALL TIMES I/P FUSE BLOCK (LEFT SIDE OF DASH, ILLUMINATION LEFT I/P JUNCTION BLOCK (LOWER LEFT SIDE OF DASH) LEFT REAR WINDOW MOTOR (IN LEFT REAR DOOR) LEFT REAR WINDOW SWITCH LOGIC ACCESSORY VOLTAGE LOGIC B+ LOGIC B+ VOLT LR WINDOW LT BLU WIRE LT BLU/WHT WIRE LT DR CIRCUIT BREAKER LT GRN WIRE PASSENGER WINDOW PASSENGER WINDOW MOTOR (INSIDE PASSENGER'S DOOR) PASSENGER WINDOW SWITCH PPL PWR WND LOCKOUT LR SIGNAL PWR WND LOCKOUT RR CONTROL PWR WND LOCKOUT RR CTRL PWR WND LOCKOUT SIG PWR WND MOTOR LF DOWN CTRL PWR WND MOTOR LF UP CTRL PWR WND MOTOR LR DOWN CTRL PWR WND MOTOR LR UP CTRL PWR WND MOTOR RF DOWN CTRL PWR WND MOTOR RF UP CTRL PWR WND MOTOR RR DOWN CTRL PWR WND MOTOR RR UP CTRL PWR WND SW LR DOWN SIG PWR WND SW LR UP SIG PWR WND SW PASS DOWN SIG PWR WND SW PASS UP SIG PWR WND SW RR DOWN SIG PWR WND SW RR UP SIG PWR WND SWITCH LR DOWN SIGNAL PWR WND SWITCH LR UP SIGNAL PWR WND SWITCH RR DOWN SIGNAL PWR WND SWITCH RR UP SIGNAL RED/WHT WIRE RIGHT REAR WINDOW MOTOR (IN RIGHT REAR DOOR) RIGHT REAR WINDOW SWITCH RR WINDOW RT DOORS CIRCUIT TAN WIRE UP EXPRS DOWN WINDOW DOWN WINDOW DRIVER WINDOW SWITCH WINDOW UP YEL WIRE
