Keyless entry circuit, 4 door for Chevrolet Cab & Chassis K3500 (1989-2000)

BATTERY LIFTGATE RELEASE OUT BLK WIRE BLK/WHT WIRE CIG LTR FUSE 14 CONVENIENCE CENTER DATA LINK CONNECTOR DOOR LOCK RELAY UNLOCK FUSE BLOCK (LOWER LEFT SIDE OF I/P) GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES PWR ACCY CIRCUIT BREAKER A HOT IN RUN, BULB TEST OR START GAUGES FUSE 4 KEYLESS ENTRY MODULE (BEHIND CENTER OF I/P) L FNT DR UNLK OUT JAMB SWITCH INPUT GROUND LEFT FRONT DOOR LOCK MOTOR LEFT FRONT DOOR LOCK SWITCH LEFT REAR DOOR LOCK MOTOR LOCK LOCK DOORS OUT UNLK DOORS OUT LT BLU WIRE ORG/ WIRE PNK IGNITION WIRE PNK WIRE PROGRAM ENABLE INPUT RIGHT FRONT DOOR LOCK MOTOR RIGHT FRONT DOOR LOCK SWITCH RIGHT REAR DOOR LOCK MOTOR TAN WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM UNLOCK WHT WIRE
