Overhead console lamps circuit for Chevrolet Cab & Chassis K3500 (1989-2000)
Overhead console lamps circuit
BLK WIRE
COURTESY LAMPS CIRCUIT
CTSY FUSE 3
FRONT DOME/ READING LAMPS
HEADLAMP, PANEL DIMMER SWITCH COURTESY LAMPS
HOT AT ALL TIMES
I/P FUSE BLOCK
INT LAMP OUTPUT
ORG/ WIRE
OVERHEAD CONSOLE READING LAMPS
REAR DOME READING LAMPS
REMOTE CONTROL DOOR LOCK RECEIVER (W/RKE) (BEHIND CENTER OF DASH)
WHT WIRE
