Chevrolet Cab & Chassis K2500 (1989-2000) wait to bat ind Wiring diagram
This page shows the only wiring diagram for the component.wait to bat ind, which is found in the car Chevrolet Cab & Chassis K2500 (1989-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wait to bat ind (1 of 1)
39 (OR 1020)
AIR BAG IND
ANTI- LOCK BRAKES IND
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLK/WHT WIRE
BRAKE IND
BRN WIRE
BRN/WHT WIRE
CHECK GAUGES IND
CHECK GAUGES LAMP DRIVER
DAYTIME RUNNING LAMPS IND
DIMMING LED
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROLS SYSTEM
FUEL GAUGE
FUEL PUMP/ OIL PRESSURE SWITCH, SENDER (UNDER INTAKE MANIFOLD, CENTER OF ENGINE)
GENERATOR
GRY WIRE
HEADLIGHTS SYSTEM
HI-BEAM IND
IGN
ILLUMINATION
IND
INSTRUMENT CLUSTER
LOW COOLANT IND
LOW COOLANT LEVEL INDICATOR MODULE (BEHIND CENTER OF DASH)
LOW COOLANT LEVEL SWITCH (IN COOLANT RESERVOIR, RIGHT SIDE OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
OIL PRESS
PNK PNK WIRE
PNK PPL WIRE
PNK WIRE
PPL
PPL/WHT WIRE
PRNDL
PRNDL A
PRNDL B
PRNDL C
PRNDL PARITY
RIGHT TURN IND LEFT TURN IND
SAFETY BELT IND
SECURITY IND
SERVICE ENGINE SOON IND
SERVICE THROTTLE SOON IND
SOLID STATE
SPEED- OMETER
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TACH
TAN WIRE
TAN/WHT WIRE
TEMP GAUGE
TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION)
VOLT- METER
WAIT TO BAT IND
WARNING SYSTEMS
WATER IN FUEL IND
WATER IN-FUEL SENSOR (ON FUEL FILTER/ MANAGER)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 6.5l (vin f), instrument cluster circuit (1 of 2) -> WAIT TO BAT IND
