Chevrolet Cab & Chassis K2500 (1989-2000) pnk ignition dome lmp off program sig Wiring diagram
This page shows the only wiring diagram for the component.pnk ignition dome lmp off program sig, which is found in the car Chevrolet Cab & Chassis K2500 (1989-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk ignition dome lmp off program sig (1 of 1)
BATT B
BELT SWITCH BREAKOUT)
BLK WIRE
BLK/WHT WIRE
CIG LTR FUSE 13
CONVENIENCE CENTER (LEFT SIDE OF DASH)
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DOOR LOCK RELAY (UNDER CENTER OF DASH, NEAR REMOTE CONTROL DOOR LOCK RECEIVER)
DRIVER DR UNLK UNLOCK OUT HORN SIGNAL
GAUGES FUSE 4
GROUND
GRY WIRE
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (LEFT SIDE OF DASH,
INTERIOR LAMPS SYSTEM
LEFT DOOR LOCK SWITCH
LEFT FRONT DOOR LOCK ACTUATOR
LOCK
LOCK OUT DOME LAMPS
LT BLU WIRE
ORG/ WIRE
PASS DRS UNLK
PNK IGNITION DOME LMP OFF PROGRAM SIG WIRE
PNK WIRE
PWR ACCY C.B.
REMOTE CONTROL DOOR LOCK RECEIVER (UNDER CENTER OF DASH PANEL)
RIGHT DOOR LOCK SWITCH
RIGHT FRONT DOOR LOCK ACTUATOR
SEAT BELT SWITCH BREAKOUT)
TAN WIRE
UNLOCK
W/O POWER WINDOWS W/ POWER WINDOWS
WHT WIRE
Go to component -> Keyless entry circuit, without crew cab -> PNK IGNITION DOME LMP OFF PROGRAM SIG WIRE
