Chevrolet Cab & Chassis K2500 (1989-2000) pick-up w/ extended or crew cab Wiring diagram
This page shows the only wiring diagram for the component.pick-up w/ extended or crew cab, which is found in the car Chevrolet Cab & Chassis K2500 (1989-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pick-up w/ extended or crew cab (1 of 1)
BLK WIRE
BRN WIRE
CONVENIENCE CENTER (UNDER LEFT SIDE OF DASH)
FUSE/RELAY BLOCK (LEFT REAR OF ENGINE COMPT)
HEATED MIRROR RELAY (BEHIND LEFT SIDE OF DASH, ABOVE SUPPORT BRACKET)
HOT IN RUN
HOT IN RUN OR START
HTR A/C FUSE 12
HVAC CONTROL MODULE (IN CENTER OF DASH)
I/P FUSE BLOCK (UNDER LEFT SIDE OF DASH)
LEFT CARGO DOOR CONTACTOR
LEFT HEATED MIRROR
LEFT POWER OUTSIDE REAR VIEW MIRROR
LEFT REAR CARGO DOOR DEFOGGER GRID
MIRRORS FUSE
ORG/ WIRE
PICK-UP W/ EXTENDED OR CREW CAB
PPL
REAR WINDOW DEFOGGER GRID
REAR WINDOW DEFOGGER SWITCH
RIGHT CARGO DOOR CONTACTOR
RIGHT HEATED MIRROR
RIGHT REAR CARGO DOOR DEFOGGER GRID
RR DEFOG FUSE
SOLID STATE TIME DELAY RELAY
SUBURBAN/UTILITY W/ LIFTGATE
SUBURBAN/UTILITY W/O LIFTGATE
W/ HEATED MIRRORS
Go to component -> Defogger circuit -> PICK-UP W/ EXTENDED OR CREW CAB
