Chevrolet Cab & Chassis K2500 (1989-2000) lt frt spkr lt frt spkr rt frt spkr rt frt spkr ground park lamp dimmer Wiring diagram
This page shows the only wiring diagram for the component.lt frt spkr lt frt spkr rt frt spkr rt frt spkr ground park lamp dimmer, which is found in the car Chevrolet Cab & Chassis K2500 (1989-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lt frt spkr lt frt spkr rt frt spkr rt frt spkr ground park lamp dimmer (1 of 1)
ANTENNA
ANTENNA INPUT
BLK WIRE
BRN WIRE
COAXIAL CABLE
CTSY FUSE
DK GRN WIRE
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRY WIRE
HOT AT ALL TIMES
HOT IN ACCY OR RUN
IGN MEMORY(BAT)
LEFT FRONT SPEAKER
LT FRT SPKR LT FRT SPKR RT FRT SPKR RT FRT SPKR GROUND PARK LAMP DIMMER
LT GRN WIRE
ORG/ WIRE
RADIO
RADIO FUSE
RIGHT FRONT SPEAKER
TAN WIRE
YEL WIRE
Go to component -> 2-speaker system circuit -> LT FRT SPKR LT FRT SPKR RT FRT SPKR RT FRT SPKR GROUND PARK LAMP DIMMER
