Chevrolet Cab & Chassis K2500 (1989-2000) down auto window down module Wiring diagram
This page shows the only wiring diagram for the component.down auto window down module, which is found in the car Chevrolet Cab & Chassis K2500 (1989-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram down auto window down module (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CONVENIENCE CENTER (UNDER LEFT SIDE OF DASH)
DK BLU WIRE
DOWN
DOWN AUTO WINDOW DOWN MODULE
DOWN UP
HOT IN RUN
I/P FUSE BLOCK (UNDER LEFT SIDE OF DASH)
LEFT FRONT
LEFT FRONT WINDOW MOTOR
LEFT POWER WINDOW MASTER SWITCH
LT BLU WIRE
PWR WDO CIRCUIT BREAKER
RIGHT FRONT
RIGHT FRONT WINDOW MOTOR
RIGHT FRONT WINDOW SWITCH
SOLID STATE
TAN WIRE
YEL WIRE
Go to component -> Power window circuit, 2 door -> DOWN AUTO WINDOW DOWN MODULE
