Chevrolet Cab & Chassis K2500 (1989-2000) body rear radio control stereo module controller Wiring diagram
This page shows the only wiring diagram for the component.body rear radio control stereo module controller, which is found in the car Chevrolet Cab & Chassis K2500 (1989-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body rear radio control stereo module controller (1 of 1)
A/T M/T
AIR BAG FUSE 10
BODY CONTROL MODULE
BODY REAR RADIO CONTROL STEREO MODULE CONTROLLER
BRN WIRE
CLUTCH PEDAL PARK/NEUTRAL POSITION POSITION SWITCH SWITCH
COLUMN HARN BREAKOUT) PNK WIRE
CONVENIENCE CENTER
CRANK FUSE 8
DAYTIME RUNNING LAMPS MODULE
DK BLU WIRE
ELECTROCHROMIC REARVIEW MIRROR W/ COMPASS
FROM CONVENIENCE CENTER BREAKOUT)
FROM IGNITION SWITCH (DIAGRAM 3 OF 5)
FROM UNDERHOOD FUSE BLOCK
GAS DIESEL
GAUGES FUSE 4
HEADLAMP, PANEL DIMMER SWITCH
I/P FUSE BLOCK
IGN A FUSE 6
IGN B FUSE 5
IGNITION SWITCH
INFLATABLE RESTRAINT I/P MODULE SWITCH (PICKUP)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INTERIOR LAMP CONTROL MODULE OR REMOTE CONTROL DOOR LOCK RECEIVER
LOCK OFF
LUXURY
LUXURY ONLY
M/T
M/T A/T
ORG/ WIRE
OTHERS
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
PWR WDO CIRCUIT BREAKER
RADIO BATT FUSE 17
REAR WINDOW LOCKOUT SWITCH (4-DR)
RED WIRE
RR WIPER FUSE 23 TRANS FUSE 20 WIPER FUSE 11
RUN WIRE
STARTER RELAY
TO UNDERHOOD FUSE BLOCK (DIAGRAM 4 OF 5) PNK WIRE
TO UNDERHOOD FUSE BLOCK (DIAGRAM 5 OF 5)
TRANSFER CASE SELECT SWITCH
TURN B/U FUSE 16
UNDERHOOD FUSE BLOCK
VEHICLE RIGHT FRONT INTERFACE POWER UNIT WINDOW SWITCH (2 DR, UTILITY)
VEHICLE SPEED SENSOR BUFFER (DIESEL)
W/O RKE W/ RKE
WHT WIRE
WINDSHIELD WIPER INSTRUMENT MOTOR CLUSTER MODULE
YEL WIRE
Go to component -> Power distribution circuit (3 of 5) -> BODY REAR RADIO CONTROL STEREO MODULE CONTROLLER
