Chevrolet Cab & Chassis K2500 (1989-2000) 1827 33 vss sig ind out serial data line Wiring diagram

1827 33 VSS SIG IND OUT SERIAL DATA LINE ABS FUSE ABS IND. BLK WIRE BLK/WHT WIRE BRAKE FUSE 18 BRAKE IND BRAKE SW OUTPUT BRN WIRE DAYTIME RUNNING LAMPS MODULE (LEFT SIDE OF DASH) DK GRN WIRE EBCM GROUND ELECTRONIC BRAKE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) HOT AT ALL TIMES HOT IN RUN HOT IN RUN, BULB TEST OR START GAUGES FUSE 4 I/P FUSE BLOCK IGN ABS LAMP CONTROL BRAKE SW INPUT INSTRUMENT CLUSTER LEFT FRONT WHEEL SPEED SENSOR LFT FRT SENSOR (-) LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE PNK WIRE PPL PPL/WHT WIRE PUMP MOTOR POWER PUMP MOTOR GROUND RED WIRE RIGHT FRONT WHEEL SPEED SENSOR RT FRT SENSOR (-) LFT FRT SENSOR (+) RT FRT SENSOR (+) TAN WIRE TAN/WHT WIRE TCC/ STOPLAMP SWITCH (TOP OF BRAKE PEDAL) UNDERHOOD FUSE-RELAY CENTER VEHICLE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (LEFT SIDE OF TRANSMISSION/ TRANSFER CASE) VEHICLE SPEED SIG VSS YEL WIRE YEL/BLK WIRE
