Chevrolet Cab & Chassis C3500 (1989-2000) primary tank fuel level sensor Wiring diagram
This page shows the only wiring diagram for the component.primary tank fuel level sensor, which is found in the car Chevrolet Cab & Chassis C3500 (1989-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram primary tank fuel level sensor (1 of 1)
"GLOW PLUGS" INDICATOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ECM-B FUSE
FUEL BALANCE PUMP
FUEL GAUGE
FUEL PUMP BALANCE MODULE (INSIDE LEFT SIDE FRAME RAIL)
FUEL PUMP BALANCE RELAY (ON FUEL PUMP BALANCE MODULE)
FUEL PUMP PRIME CONNECTOR (LEFT SIDE OF ENG COMPT)
FUEL PUMP RELAY (IN UNDER FUSE- RELAY CENTER)
FUEL PUMP/OIL PRESSURE SWITCH
GAUGES FUSE 4
GRN WIRE
GRY WIRE
HOT AT ALL TIMES UNDERHOOD FUSE/RELAY CENTER
HOT IN RUN OR START
I/P FUSE BLOCK
IGN E FUSE
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK PNK 8 9 WIRE
PNK PNK PNK WIRE
PNK WIRE
PPL
PRIMARY TANK FUEL LEVEL SENSOR
RED WIRE
SERVICE ENGINE SOON INDICATOR
SERVICE THROTTLE SOON INDICATOR
TAN WIRE
VEHICLE SPEED INPUT
W/ DUAL TANKS W/O DUAL TANK
W/O DUAL TANK W/ DUAL TANKS
WAIT TO
WATER IN FUEL INDICATOR
WATER IN-FUEL SENSOR (ON FUEL FILTER/ MANAGER)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 6.5l (vin f)s (3 of 4) -> PRIMARY TANK FUEL LEVEL SENSOR
