Chevrolet Bolt I (2016-2021) Rear heated seats circuit

BATT POS VOLT BATTERY POS VOLT BCM 1 FUSE BLK WIRE BLU WIRE BODY CONTROL MODULE (RIGHT END OF DASH) BRN/BLK WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRY WIRE HI SPD GMLAN SERIAL DATA (-) (1) HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK LEFT REAR CUSHION SEAT HEATING ELEMENT LEFT REAR SEAT HEATING SWITCH LOCAL INTERCONNECT NETWORK SERIAL DATA BUS 2 LR HTD SEAT CUSHION ELEMENT LO REF LR HTD SEAT CUSHION ELEMENT CTRL LR HTD SEAT HIGH IND CTRL LR HTD SEAT NTC LO REF LR HTD SEAT NTC SIG LR HTD SEAT SW SIG REAR SEAT HEATING CONTROL MODULE RED/BLU WIRE RED/VIO WIRE RIGHT REAR CUSHION SEAT HEATING ELEMENT RIGHT REAR SEAT HEATING SWITCH RR CUSHION NTC LO REF RR CUSHION NTC SIG RR HTD SEAT CUSHION ELEMENT CTRL RR HTD SEAT CUSHION ELEMENT LO REF RR HTD SEAT HIGH IND CTRL RR HTD SEAT SW SIG SEAT MODULE REAR FUSE UNDERHOOD FUSE BLOCK VIO/RED WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/WHT WIRE
