Chevrolet Bolt I (2016-2021) w/ rear view vision Wiring diagram
This page shows the only wiring diagram for the component.w/ rear view vision, which is found in the car Chevrolet Bolt I (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ rear view vision (1 of 1)
AMBIENT LIGHT/ SUNLOAD SENSOR, BATTERY STATE OF CHARGE INDICATOR
AUDIO AMPLIFIER
AUXILIARY AUDIO INPUT
BLK WIRE
BLK/WHT WIRE
INFO DISPLAY MODULE
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 1
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 2
LEFT SIDE OBJECT SENSOR MODULE
LIFTGATE LATCH ASSEMBLY
NCA WIRE
RADIO
RADIO/ HVAC CONTROLS
REAR DEFOGGER GRID
REAR SEAT HEATING CONTROL MODULE
REAR VIEW CAMERA
REAR WIPER MOTOR
RIGHT AUXILIARY TAIL LAMP ASSEMBLY
RIGHT AUXILIARY TAIL/STOP LAMP
RIGHT BACKUP LAMP
RIGHT REAR SIDE MARKER LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT SIDE OBJECT SENSOR MODULE
RIGHT TAIL LAMP ASSEMBLY
SHORT RANGE REMOTE CONTROL TRANSCEIVER
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
VIDEO PROCESSING CONTROL MODULE
W/ OBSTACLE DETECTION ENHANCED SIDE ACTIVE SAFETY
W/ ONSTAR
W/ REAR HEATER SEAT
W/ REAR VIEW VISION
W/ TAIL, STOP LAMP
W/O REAR HEATER SEAT
Go to component -> Ground distribution circuit (4 of 6) -> W/ REAR VIEW VISION
