Chevrolet Bolt I (2016-2021) rr stop lamp ctrl Wiring diagram
This page shows the only wiring diagram for the component.rr stop lamp ctrl, which is found in the car Chevrolet Bolt I (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr stop lamp ctrl (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COIL CTRL
COMPUTER DATA LINES SYSTEM
CTRL
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/YEL WIRE
LEFT FRONT TURN SIGNAL LAMP
LEFT PRK LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TAIL/ STOP LAMP
LOGIC
LOW SPD GMLAN
LR STOP LAMP CTRL
LR SUPPLEMENTAL
PASSENGER OUTSIDE REAR VIEW MIRROR
RED WIRE
RIGHT FRONT TURN SIGNAL LAMP
RIGHT PRK LAMP
RIGHT TAIL LAMP ASSEMBLY
RIGHT TAIL/ STOP LAMP
RIGHT TURN SIGNAL REPEATER LAMP
RR STOP LAMP CTRL
RR SUPPLEMENTAL
SERIAL DATA
STOP LAMP CTRL
STOP LAMP RLY
TRAILER INTERFACE CONTROL MODULE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
VIO WIRE
VIO/BLU WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ 360 VIEW VISION W/O 360 VIEW VISION
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 4) -> RR STOP LAMP CTRL
