Chevrolet Bolt I (2016-2021) right prk lamp ctrl wiring diagram
This page shows the only wiring diagram for the component.right prk lamp ctrl, which is found in the car Chevrolet Bolt I (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right prk lamp ctrl wiring diagram (1 of 1)
AUTO
BATT POSITIVE VOLT
BCM 1 FUSE
BCM 4 FUSE
BCM 5 FUSE
BCM 6 FUSE
BCM 7 FUSE
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (RIGHT END OF DASH)
BRK APPLY SENS CTRL
BRK APPLY SENS SIG
BRN/YEL WIRE
CENTER HIGH MOUNTED STOP LAMP
CHMSL CTRL
COMPUTER DATA LINES SYSTEM
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
GRY/BRN WIRE
GRY/YEL WIRE
HAZ LED DIM SIG
HAZ SW SIG
HAZARD IND
HAZARD SWITCH
HEAD
HEADLAMP SWITCH
HI SPD GMLAN SER DATA (+) 1
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
LAMP HARNESS)
LEFT LICENSE PLATE LAMP
LEFT PRK LAMP CTRL
LEFT TURN SIGNAL
LF TURN SIG LAMP CTRL
LICENSE PLATE
LO REF
LR TURN SIG LAMP CTRL
OFF
OFF SIG CTRL
PARK
PRK LAMP SIG
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RF TURN SIG LAMP CTRL
RIGHT LICENSE PLATE LAMP
RIGHT PRK LAMP CTRL
RIGHT TURN SIGNAL
RR LICENSE LAMP CTRL
RR TURN SIG LAMP CTRL
VIO/BLU WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
Go to component -> Exterior lamps circuit (1 of 4) -> RIGHT PRK LAMP CTRL
