Chevrolet Bolt I (2016-2021) pfaf fuse Wiring diagrams
This page contains all the electrical diagrams for the component. pfaf fuse, in which he is found in the car Chevrolet Bolt I (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
pfaf fuse wiring diagram (1 of 3)
BATTERY POSITIVE VOLT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
PEDESTRIAN ALERT SOUND CONTROL MODULE
PEDESTRIAN ALERT SOUND SPEAKER
PEDESTRIAN FRIENDLY ALERT SPKR CTRL (+)
PFAF FUSE
RED/BLU WIRE
RIGHT END OF DASH)
SERIAL DATA COMMUNICATION ENABLE
UNDERHOOD FUSE BLOCK
VIO/BRN WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Active bodyworks circuit -> PFAF FUSE
pfaf fuse wiring diagram (2 of 3)
AUX OIL PUMP FUSE
AUXILIARY COOLANT PUMP RELAY
BATTERY CHARGER
BATTERY CHARGER CONTROL MODULE
BLU WIRE
BRAKE BOOSTER CONTROL MODULE
DRIVER WINDOW MOTOR
DRIVER WINDOW/ OUTSIDE REAR VIEW MIRROR SWITCH
E-BOOSTER (ECU) FUSE
E-BOOSTER MOTOR SRC FUSE
ELECTRIC/ AUXILIARY TRANSMISSION FLUID PUMP
ENGINE CONTROLS IGNITION RELAY
FROM IGNITION MAIN RELAY 1 (DIAGRAM 2 OF 6)
GRN WIRE
GRY WIRE
HEADLAMP HIGH BEAM RELAY
HEADLAMP LOW BEAM RELAY
HORN RELAY
IOS FUSE
LIFTGATE UNLATCH RELAY
OBCM FUSE
PASSENGER PRESENCE MODULE
PASSENGER WINDOW SWITCH
PEDESTRIAN ALERT SOUND CONTROL MODULE
PFAF FUSE
PLCM FUSE
POWER LINE COMMUNICATION MODULE
POWER WINDOW FRONT FUSE
PROVISION FUSE
REAR DEFOGGER RELAY
REAR LIFTGATE FUSE
REAR SEAT HEATING CONTROL MODULE
REAR WINDOW WASHER PUMP RELAY
REAR WIPER FUSE
REAR WIPER MOTOR
REAR WIPER RELAY
RED WIRE
SEAT MODULE REAR FUSE
VIO WIRE
W/ FAST CHARGING ACCOMMODATIONS PROVISIONS
WASHER FUSE
WHT WIRE
WINDOW SWITCH FUSE
WINDSHIELD WASHER PUMP RELAY
YEL WIRE
Go to component -> Power distribution circuit (4 of 6) -> PFAF FUSE
pfaf fuse wiring diagram (3 of 3)
BATTERY POSITIVE VOLT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
PEDESTRIAN ALERT SOUND CONTROL MODULE
PEDESTRIAN ALERT SOUND SPEAKER
PEDESTRIAN FRIENDLY ALERT SPKR CTRL (+)
PFAF FUSE
RED/BLU WIRE
RIGHT END OF DASH)
SERIAL DATA COMMUNICATION ENABLE
UNDERHOOD FUSE BLOCK
VIO/BRN WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Wiring diagram engine performance electric, virtual engine sound system circuit -> PFAF FUSE
