Chevrolet Bolt I (2016-2021) passenger side object detection indicator Wiring diagram
This page shows the only wiring diagram for the component.passenger side object detection indicator, which is found in the car Chevrolet Bolt I (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side object detection indicator (1 of 1)
BLK WIRE
BLU/WHT WIRE
BRN/BLK WIRE
BRN/YEL WIRE
DEFOGGER SYSTEM
DOWN
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR VIEW MIRROR MOTOR
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SIDE OBJECT DETECTION INDICATOR
DRIVER WINDOW/ OUTSIDE REAR VIEW MIRROR SWITCH
GRN/BLK WIRE
GRN/VIO WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT
LEFT TURN SIGNAL REPEATER LAMP
NAVIGATION SYSTEM
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
PASSENGER OUTSIDE REAR VIEW MIRROR MOTOR
PASSENGER SIDE OBJECT DETECTION INDICATOR
RED/GRN WIRE
RIGHT
RIGHT TURN SIGNAL REPEATER LAMP
UNDERHOOD FUSE BLOCK
VIO/BLU WIRE
WHT WIRE
WINDOW SWITCH
YEL/BRN WIRE
YEL/VIO WIRE
Go to component -> Power mirrors circuit -> PASSENGER SIDE OBJECT DETECTION INDICATOR
