Chevrolet Bolt I (2016-2021) night vision signal Wiring diagram
This page shows the only wiring diagram for the component.night vision signal, which is found in the car Chevrolet Bolt I (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram night vision signal (1 of 1)
BACKUP LP CTRL
BLK WIRE
DIMMING CONTROL SWITCH
DISPLAY
GRN/WHT WIRE
GROUND
HI PASS
HOT W/ IGNITION MAIN RELAY ENERGIZED
INFO SWITCH
INSIDE REAR VIEW MIRROR
ISRVM FUSE
LOGIC
LVDS
LVDS BK
LVDS BU
MIRROR DIMMING
NIGHT VISION SIGNAL
ON/OFF SWITCH
REAR VIEW CAMERA
RED LED WIRE
RUN/CRANK IGN 1 VOLT
ULTRASONIC
UNDERHOOD FUSE BLOCK
VIO/BLK WIRE
VOLUME SWITCH
Go to component -> Electrochromic mirror circuit -> NIGHT VISION SIGNAL
