Chevrolet Bolt I (2016-2021) hybrid/ev battery pack fuse holder 1 Wiring diagram
This page shows the only wiring diagram for the component.hybrid/ev battery pack fuse holder 1, which is found in the car Chevrolet Bolt I (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hybrid/ev battery pack fuse holder 1 (1 of 1)
BATTERY CHARGING SYSTEM POSITIVE CONTACTOR
BLK WIRE
BRN/GRN WIRE
DC BATTERY CHARGER
FROM HYBRID/EV BATTERY MODULE 10 (DIAGRAM 16 OF 16)
FUSE 1
GRY WIRE
HYBRID/EV BATTERY CONTACTOR ASSEMBLY
HYBRID/EV BATTERY NEGATIVE CONTACTOR
HYBRID/EV BATTERY PACK
HYBRID/EV BATTERY PACK FUSE HOLDER 1
HYBRID/EV BATTERY POSITIVE CONTACTOR
HYBRID/EV BATTERY PRECHARGE RESISTOR
LOGIC
ORG/ WIRE
ORG/BLK WIRE
PRECHARGE CONTACTOR
TO DC BATTERY CHARGER (DIAGRAM 7 OF 16)
TO HYBRID/EV BATTERY PACK CURRENT SENSOR (DIAGRAM 11 OF 16)
VIO/GRY WIRE
W/O HIGH VOLTAGE CONTACTORS W/ HIGH VOLTAGE CONTACTORS
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance electric, engine controls circuit (12 of 16) -> HYBRID/EV BATTERY PACK FUSE HOLDER 1
