Chevrolet Bolt I (2016-2021) hybrid/ev battery module 10 Wiring diagrams
This page contains all the electrical diagrams for the component. hybrid/ev battery module 10, in which he is found in the car Chevrolet Bolt I (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hybrid/ev battery module 10 (1 of 2)
BATTERY ENERGY CONTROL MODULE
BATTERY POS VOLT
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN/GRN WIRE
COMMUNICATION CTRL
COMPUTER DATA LINES SYSTEM
COURSE SIG
FAULT SIGNAL
FROM HYBRID/EV BATTERY NEGATIVE CONTACTOR (DIAGRAM 12 OF 16)
GRN WIRE
GROUND
GRY WIRE
HI SIG 2
HIGH SPD SER DATA (+) (1)
HIGH SPD SER DATA (-) 6
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY 2 ENERGIZED
HYBRID/EV BATTERY CONTACTOR ASSEMBLY
HYBRID/EV BATTERY MODULE 1
HYBRID/EV BATTERY MODULE 10
HYBRID/EV BATTERY MODULE 2
HYBRID/EV BATTERY MODULE 5
HYBRID/EV BATTERY MODULE 6
HYBRID/EV BATTERY MODULE 8
HYBRID/EV BATTERY PACK CURRENT SENSOR
HYBRID/EV BATTERY TEMPERATURE SENSOR 1
HYBRID/EV BATTERY TEMPERATURE SENSOR 2
HYBRID/EV BATTERY TEMPERATURE SENSOR 3
HYBRID/EV BATTERY TEMPERATURE SENSOR 4
HYBRID/EV BATTERY TEMPERATURE SENSOR 5
HYBRID/EV BATTERY TEMPERATURE SENSOR 6
IGN 1 VOLT
LOW REF
LOW REF (6)
LOW REF 2
LOW REF 3
LOW REF 5
LOW REF 7
RED WIRE
RED/VIO WIRE
RESS 1 FUSE
RESS FUSE
SENS FINE SIG
TEMP SIG 2
TEMP SIG 3
TEMP SIG 4
TEMP SIG 5
TEMP SIG 6
TEMP SIG 7
TO HYBRID/EV BATTERY MODULE 1 (DIAGRAM 13 OF 16)
UNDERHOOD FUSE BLOCK
VICM FUSE
VIO WIRE
VIO/BLK WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VOLT REF
WAKEUP SERIAL DATA 2
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance electric, engine controls circuit (11 of 16) -> HYBRID/EV BATTERY MODULE 10
Wiring diagram hybrid/ev battery module 10 (2 of 2)
BATT VOLT SIG 64
BATT VOLT SIG 65
BATT VOLT SIG 66
BATT VOLT SIG 67
BATT VOLT SIG 68
BATT VOLT SIG 69
BATT VOLT SIG 70
BATT VOLT SIG 71
BATT VOLT SIG 72
BATT VOLT SIG 73
BATT VOLT SIG 74
BATT VOLT SIG 75
BATT VOLT SIG 76
BATT VOLT SIG 77
BATT VOLT SIG 78
BATT VOLT SIG 79
BATT VOLT SIG 80
BATT VOLT SIG 81
BATT VOLT SIG 82
BATT VOLT SIG 83
BATT VOLT SIG 84
BATT VOLT SIG 85
BATT VOLT SIG 86
BATT VOLT SIG 87
BATT VOLT SIG 88
BATT VOLT SIG 89
BATT VOLT SIG 90
BATT VOLT SIG 91
BATT VOLT SIG 92
BATT VOLT SIG 93
BATT VOLT SIG 94
BATT VOLT SIG 95
BATT VOLT SIG 96
BATTERY ENERGY CONTROL MODULE
BLU WIRE
BRN WIRE
FROM HYBRID/EV BATTERY MODULE 7 (DIAGRAM 15 OF 16)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HYBRID/EV BATTERY MODULE 10
HYBRID/EV BATTERY MODULE 8
HYBRID/EV BATTERY MODULE 9
HYBRID/EV BATTERY PACK (UNDER CENTER OF VEHICLE)
HYBRID/EV BATTERY SECTION 1
HYBRID/EV BATTERY SECTION 2
HYBRID/EV BATTERY SECTION 3
LOW REF
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
TO HYBRID/EV BATTERY CONTACTOR ASSEMBLY (DIAGRAM 12 OF 16)
TO HYBRID/EV BATTERY MODULE 7 (DIAGRAM 15 OF 16)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance electric, engine controls circuit (16 of 16) -> HYBRID/EV BATTERY MODULE 10
