Chevrolet Bolt I (2016-2021) fault signal Wiring diagram
This page shows the only wiring diagram for the component.fault signal, which is found in the car Chevrolet Bolt I (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fault signal (1 of 1)
BATTERY ENERGY CONTROL MODULE
BATTERY POS VOLT
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN/GRN WIRE
COMMUNICATION CTRL
COMPUTER DATA LINES SYSTEM
COURSE SIG
FAULT SIGNAL
FROM HYBRID/EV BATTERY NEGATIVE CONTACTOR (DIAGRAM 12 OF 16)
GRN WIRE
GROUND
GRY WIRE
HI SIG 2
HIGH SPD SER DATA (+) (1)
HIGH SPD SER DATA (-) 6
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY 2 ENERGIZED
HYBRID/EV BATTERY CONTACTOR ASSEMBLY
HYBRID/EV BATTERY MODULE 1
HYBRID/EV BATTERY MODULE 10
HYBRID/EV BATTERY MODULE 2
HYBRID/EV BATTERY MODULE 5
HYBRID/EV BATTERY MODULE 6
HYBRID/EV BATTERY MODULE 8
HYBRID/EV BATTERY PACK CURRENT SENSOR
HYBRID/EV BATTERY TEMPERATURE SENSOR 1
HYBRID/EV BATTERY TEMPERATURE SENSOR 2
HYBRID/EV BATTERY TEMPERATURE SENSOR 3
HYBRID/EV BATTERY TEMPERATURE SENSOR 4
HYBRID/EV BATTERY TEMPERATURE SENSOR 5
HYBRID/EV BATTERY TEMPERATURE SENSOR 6
IGN 1 VOLT
LOW REF
LOW REF (6)
LOW REF 2
LOW REF 3
LOW REF 5
LOW REF 7
RED WIRE
RED/VIO WIRE
RESS 1 FUSE
RESS FUSE
SENS FINE SIG
TEMP SIG 2
TEMP SIG 3
TEMP SIG 4
TEMP SIG 5
TEMP SIG 6
TEMP SIG 7
TO HYBRID/EV BATTERY MODULE 1 (DIAGRAM 13 OF 16)
UNDERHOOD FUSE BLOCK
VICM FUSE
VIO WIRE
VIO/BLK WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VOLT REF
WAKEUP SERIAL DATA 2
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance electric, engine controls circuit (11 of 16) -> FAULT SIGNAL
