Chevrolet Bolt I (2016-2021) ecm fuse 58 Wiring diagram
This page shows the only wiring diagram for the component.ecm fuse 58, which is found in the car Chevrolet Bolt I (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ecm fuse 58 (1 of 1)
ACCM FUSE 70
BATTERY ENERGY CONTROL MODULE HYBRID/EV BATTERY PACK
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE BOOSTER CONTROL MODULE
CHASSIS CONTROL MODULE
E-BOOSTER FUSE
ECM FUSE 58
ELECTRIC A/C COMPRESSOR CONTROL MODULE
ENGINE CONTROL MODULE
ESCL FUSE
FROM FRONT WIPER MOTOR CO-DRIVER FUSE (DIAGRAM 1 OF 6)
GRN WIRE
GRY WIRE
HYBRID/EV POWERTRAIN CONTROL MODULE 1
HYBRID/EV POWERTRAIN CONTROL MODULE 2
ICCM FUSE 48
IEC INLINE FUSE
IGNITION MAIN RELAY 1
IGNITION MAIN RELAY 2
INSIDE REAR VIEW MIRROR
ISRVM FUSE
NCA WIRE
POWER INVERTER MODULE
PROVISION FUSE
REAR CAMERA FUSE
REAR VIEW CAMERA
RESS FUSE
SPIM FUSE
STEERING COLUMN LOCK MODULE
TO POWER WINDOW FRONT FUSE (DIAGRAM 4 OF 6)
TRANSMISSION RANGE CONTROL MODULE
TRCM FUSE 72
VICM FUSE
VIO WIRE
WHT WIRE
Go to component -> Power distribution circuit (2 of 6) -> ECM FUSE 58
