Chevrolet Bolt I (2016-2021) batt pos volt ign mode sw mode volt Wiring diagram
This page shows the only wiring diagram for the component.batt pos volt ign mode sw mode volt, which is found in the car Chevrolet Bolt I (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram batt pos volt ign mode sw mode volt (1 of 1)
AUTO OFF
BATT POS VOLT IGN MODE SW MODE VOLT
BCM 1 FUSE
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/VIO WIRE
BODY CONTROL MODULE (RIGHT END OF DASH)
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRK FLUID LVL SENS SIG
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
ELECTRONIC BRAKE CONTROL MODULE (BEHIND RIGHT HEADLAMP)
GRN/GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
HEAD
HEADLAMP SW PARK LAMP SIG
HEADLAMP SWITCH
HIGH SPD GMLAN SERIAL DATA (+) 1
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LIFT GATE AJAR SW SIG 1
LOGIC
LOW SPD GMLAN SERIAL DATA 2
PARK
PARK BRAKE CONTROL SWITCH (NEXT TO TRANSMISSION SHIFT LEVER)
PARK BRAKE IND
PARK BRK APPLY SW SIG
PARK BRK APPLY SW VOLT REF
PARK BRK RELEASE SW SIG
PARK BRK RELEASE SW VOLT REF
PARK BRK SW SIG
PARK BRK SW SPLY VOLT
RED/VIO WIRE
SEAT BELT IND
TIRE PRESSURE IND
VEHICLE ON/OFF SWITCH
VIO/GRY WIRE
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Warning systems circuit (1 of 2) -> BATT POS VOLT IGN MODE SW MODE VOLT
