Shift interlock circuit, with floor shift for Chevrolet Blazer S15 facelift (1998-2005)
Shift interlock circuit, with floor shift
B/U LP FUSE
BLK WIRE
BODY RELAY BLOCK (BEHIND LEFT SIDE OF DASH)
BTSI FUSE
DK GRN WIRE
HOT IN RUN, START
LT GRN WIRE
LT GRN/BLK WIRE
PARK LOCK SOLENOID
PARK/ NEUTRAL POSITION (PNP) SWITCH (ON LEFT SIDE OF TRANSMISSION)
PNK WIRE
SPLICE
SPLICE PACK
STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
UNDERHOOD FUSE BLOCK (ON TOP OF LEFT FRONT INNER WHEELWELL)
WHT WIRE
