Chevrolet Blazer S15 facelift (1998-2005) stoplight switch Wiring diagrams
This page contains all the electrical diagrams for the component. stoplight switch, in which he is found in the car Chevrolet Blazer S15 facelift (1998-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram stoplight switch (1 of 2)
4 DOOR
4 LO REQUEST 2 HI REQUEST 4 HI REQUEST
4 LO STATUS LAMP
ANTI-LOCK BRAKES SYSTEM
ATC FUSE
AXLE SW
BLK LT GRN/ WIRE
BLK WIRE
BLK/WHT WIRE
BODY RELAY BLOCK (BEHIND LEFT SIDE OF DASH)
BRN WIRE
BRN/WHT WIRE
BTSI FUSE
CRANK FUSE
CRUISE CONTROL SYSTEM
CTSY LP FUSE 8
DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER LEFT SIDE OF DASH)
DK BLU/WHT WIRE
DK GRN/WHT WIRE
ENCODER CHANNEL A
ENCODER CHANNEL B
ENCODER CHANNEL C
ENCODER CHANNEL P
ENCODER GROUND
ENCODER SIG GROUND GROUND 2 HI STATUS LAMP 4 HI STATUS LAMP
FRONT AXLE INDICATOR
FUSE 15
GROUND GROUND BATTERY BATTERY
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN
HOT IN PARK OR NEUTRAL
I/P FUSE BLOCK (ON LEFT END OF DASH)
IGNITION
ILLUMINATION LAMP
INDICATOR
INSTRUMENT CLUSTER, SOUND SYSTEMS
LT GRN WIRE
LT GRN/ BLK WIRE
LT GRN/BLK WIRE
MOTOR CONTROL A
ORG/ WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/WHT WIRE
RUN WIRE
SHIFT MOTOR
SOLID STATE
SPLICE PACK
STARTING/ CHARGING SYSTEM
STOPLIGHT SWITCH
SWITCH
SWITCH (ON FRONT AXLE, RIGHT OF DIFF)
TAN/BLK WIRE
TRANSFER CASE ENCODER MOTOR
TRANSFER CASE SHIFT CONTROL MODULE (BEHIND RIGHT FRONT KICK PANEL)
TRANSFER CASE SHIFT CONTROL SWITCH
UNDERHOOD FUSE BLOCK (ON TOP OF LEFT FRONT FENDER)
VS SIGNAL
WHT WIRE
YEL/BLK WIRE
Go to component -> 4.3l vin w, transfer case circuit, with 2-speed selectable transfer case -> STOPLIGHT SWITCH
