Chevrolet Blazer S15 facelift (1998-2005) mir/lks fuse Wiring diagrams

58 59 59 58 (2.2L) (4.3L) BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (UNDER DASH, ON HEATER CASE) BODY RELAY BLOCK (BEHIND LEFT SIDE OF DASH, NEAR I/P FUSE BLOCK) CLASS 2 SERIAL DATA GMCM SERIAL DATA GRN WIRE HOT AT ALL TIMES LEFT DOOR LOCK CYLINDER SWITCH (INSIDE DOOR LATCH ASSEMBLY) LIFT GLASS RELEASE SW SIG LIFTGATE/ENDGATE LOCK CYLINDER SWITCH (ON BOTTOM CENTER OF LIFTGATE) LIFTGATE/ENDGATE WINDOW RELEASE ACTUATOR (IN TOP OF ENDGATE) LIFTGLASS REL RELAY CTRL LIFTGLASS RELAY LT BLU WIRE LT GRN WIRE MIR/LKS FUSE ORG/ WIRE PARK BRAKE SW SIG PARK BRAKE SWITCH (ON BASE OF PARK BRAKE ASSEMBLY) POWERTRAIN CONTROL MODULE (PCM) (ON RIGHT FRONT OF ENGINE COMPT) REAR WIPER/WASHER, ENDGATE/LIFTGATE WINDOW RELEASE SWITCH REMOTE CONTROL DOOR LOCK RECEIVER (BEHIND LOWER LEFT SIDE OF DASH) SPLICE PACK TRANSFER CASE SHIFT CONTROL SWITCH UNDERHOOD FUSE BLOCK (ON TOP OF LEFT FRONT FENDER) WHT WIRE YEL WIRE

4.3L (ENG HARN, 10 CM FROM MAP SENSOR BREAKOUT) A/C COMPRESSOR CLUTCH RELAY A/C FUSE RR W/W FUSE ATC FUSE AUTOMATIC TRANSMISSION SHIFT LOCK ACTUATOR (W/ FLOOR SHIFT A/T) BLK WIRE BLU WIRE BODY CONTROL MODULE REMOTE CONTROL DOOR LOCK RECEIVER BODY RELAY BLOCK CENTER HIGH MOUNTED STOP LAMP CRUISE CONTROL MODULE DAYTIME RUNNING LAMPS (DRL) RELAY DK BLU WIRE DK GRN WIRE DOME HIGH MOUNT STOP LAMP RESISTOR DRIVER OUTSIDE REAR VIEW MIRROR REAR WINDOW DEFOGGER GRID DRIVER SEAT HEATER MODULE DRIVER SEAT LUMBAR SWITCH FROM ATC FUSE (DIAGRAM 4 OF 5) FROM HI BEAM FUSE (DIAGRAM 3 OF 5) FROM IGNITION SWITCH FRONT PASSENGER HEATED SEAT ASSEMBLY FRONT PASSENGER SEAT LUMBAR SWITCH HEADLAMP POWER RELAY HIGH MOUNT STOP LAMP HIGH MOUNT STOP LAMP RELAY (PICKUP) HORN (A NOTE) HORN (F NOTE) HORN FUSE HORN RELAY HTD MIR FUSE RR DEFOG FUSE HTD SEAT FUSE I/P FUSE BLOCK CLSTR FUSE INSTRUMENT PANEL CLUSTER (IPC) LEFT LOW BEAM HEADLAMP RIGHT LOW BEAM HEADLAMP LIFT- GLASS RELAY (UTILITY) LT BLU WIRE LT HDLP FUSE RT HDLP FUSE LT LT MIR/LKS FUSE MULTI- FUNCTION SWITCH (FLASH TO PASS) MULTIFUNCTION SWITCH (UTILITY) NCA WIRE ORG/ WIRE OUTSIDE REAR VIEW MIRROR SWITCH DRIVER DOOR LOCK/ SIDE WINDOW SWITCH PASSENGER OUTSIDE REAR VIEW MIRROR PNK (BODY HARN, 13 CM FROM BLOWER MOTOR BREAKOUT) PNK 2.2L WIRE PNK (ENG HARN, 20 CM FROM A/C REFRIGERANT PRESSURE SENSOR BREAKOUT) PNK PNK WIRE PNK PNK WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) AUTOMATIC TRANSMISSION PPL PPL PPL PPL ESTC REAR DEFOGGER RELAY (UTILITY) REAR WINDOW WIPER MOTOR RIGHT HIGH BEAM HEADLAMP STOP LP FUSE STOPLAMP SWITCH TBC FUSE TO A/C FUSE (DIAGRAM 4 OF 5) TRAILER WIRING PROVISIONS TRANSFER CASE ENCODER MOTOR TRANSFER CASE SHIFT CONTROL MODULE TRCHMSL FUSE UNDER- HOOD FUSE BLOCK UNDER- HOOD FUSE BLOCK CRANK FUSE UTILITY VECHMSL FUSE W/ RKE WHT WIRE YEL WIRE
