Chevrolet Blazer S15 facelift (1998-2005) 710 1057 serial data sensor ret sensor sig Wiring diagram
This page shows the only wiring diagram for the component.710 1057 serial data sensor ret sensor sig, which is found in the car Chevrolet Blazer S15 facelift (1998-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 710 1057 serial data sensor ret sensor sig (1 of 1)
1850 1140 GROUND BATTERY SERIAL DATA GROUND SENSOR PWR
2.2L
4.3L
710 1057 SERIAL DATA SENSOR RET SENSOR SIG
BLK WIRE
BODY CONTROL MODULE (UNDER DASH, ON HEATER CASE)
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM (FUEL PUMP RELAY)
HOT AT ALL TIMES
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSLOCK SENSOR (AT IGNITION SWITCH)
POWERTRAIN CONTROL MODULE (ON RIGHT FRONT OF ENGINE COMPT)
PPL
RED WIRE
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (BEHIND LOWER LEFT SIDE OF DASH)
SPLICE PACK
TBC FUSE
UNDERHOOD FUSE BLOCK (ON TOP OF LEFT FRONT INNER WHEELWELL)
W/ REMOTE KEYLESS ENTRY
WHT WIRE
YEL WIRE
Go to component -> Pass-key circuit -> 710 1057 SERIAL DATA SENSOR RET SENSOR SIG
