Chevrolet Blazer S15 facelift (1998-2005) 20 21 vss low vss high Wiring diagram

2.2L 20 21 VSS LOW VSS HIGH 4.3L 46 10 17 MIL IND TACH OUT VSS OUT 54 29 69 72 73 63 ECT SENSOR IN PRNDL A PRNDL B PRNDL C PRNDL P VSS HIGH BARE BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE BRN WIRE BRN/WHT WIRE CRUISE CONTROL SYSTEM DK GRN WIRE DK GRN/ WHT WIRE DK GRN/WHT WIRE ECT SENSR GRD ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR (IN COOLANT PIPING, FRONT OF ENGINE, ENGINE COOLANT TEMPERATURE SENSOR (IN COOLANT PIPING, ON FRONT OF ENGINE) FUEL LEVEL SENS GRD FUEL PUMP/ SENDER (TOP OF FUEL TANK) FUEL PUMP/ SENSDER (TOP OF FUEL TANK) GRY WIRE LT GRN WIRE LT GRN/BLK WIRE MIL IND CTRL SERIAL DATA VSS SIG OUT ORG/BLK WIRE PARK/NEUTRAL POSITION, BACK-UP LAMP SWITCH (LEFT SIDE OF TRANSMISSION) POWERTRAIN CONTROL MODULE (2.2L ONLY) (RIGHT FRONT OF ENGINE COMPT) POWERTRAIN CONTROL MODULE (4.3L ONLY) (RIGHT FRONT OF ENGINE COMPT) PPL PPL (ENGINE HARN, NEAR BREAKOUT TO POWERTRAIN CONTROL MODULE) PPL FUEL LEVEL SIG IN PPL FUEL LVL IN PPL/WHT WIRE PRNDL C SIG PRNDL P SIG SERIAL DATA SPLICE SPLICE PACK TACH OUT TRANSMISSION VEHICLE SPEED SENSOR (RIGHT REAR OF VEHICLE SPEED SENSOR (RIGHT REAR OF TRANSMISSION) VSS LOW VSS SIG OUT WHT DK GRN/ WIRE WHT WIRE YEL WIRE
