4.3l (vin x), transmission circuit for Chevrolet Blazer S15 (1994-1998)

1-2 SHIFT SOL 10 13 29 30 TCC SOL CTRL 3-2 SOL CTRL VSS LO VSS HI 2-3 SHIFT SOL 3-2 CNTRL SOL. AUTOMATIC TRANSMISSION BLK WIRE BLK/WHT WIRE BRAKE FUSE 12 BRAVADA ONLY BREAKOUT) BRN WIRE CRUISE CONTROL DK BLU WIRE ECM BATT FUSE 9 ECM IGN FUSE 10 ENGINE CONTROLS ENGINE COOLANT TEMP SENSOR (LEFT CYLINDER HEAD) GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN AND START HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (BEHIND LEFT SIDE OF I/P) INSTRUMENT CLUSTER (BRAVADA) LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE PNK WIRE PPL PPL 2 4 5 DATA LINK CONNECTOR PPL/WHT WIRE PRESSURE CONTROL SOLENOID (PCS) RED WIRE RED/BLK WIRE TAN/BLK WIRE TAN/WHT WIRE TCC BRAKE AND CRUISE CONTROL RELEASE SWITCH (ON BRAKE PEDAL BRACKET) TCC ON/ OFF SOL. TCC PWM SOL THROTTLE POSITION SENSOR (UPPER INTAKE MANIFOLD) TRANS FUSE 24 TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR (INTERNAL) TRANSMISSION RANGE (TR) PRESSURE SWITCH ASSEMBLY VEHICLE CONTROL MODULE (VCM) (RIGHT SIDE OF ENG COMPARTMENT) VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION) WHT WIRE YEL WIRE YEL/BLK WIRE
