Door lock circuit for Chevrolet Blazer S15 (1994-1998)
Door lock circuit
1995 VFTC
BLK WIRE
CTSY FUSE 2
DOOR LOCK RELAY (BEHIND RIGHT SIDE OF I/P)
ENDGATE LOCK SWITCH
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT SIDE OF I/P)
LEFT FRONT DOOR LOCK MOTOR
LEFT FRONT DOOR LOCK SWITCH LOCK UNLOCK
LEFT REAR DOOR LOCK MOTOR (4 DOOR) RIGHT FRONT DOOR LOCK MOTOR
LOCK
LT BLU WIRE
ORG/ WIRE
PWR ACCY CIRCUIT BREAKER A
RIGHT FRONT DOOR LOCK SWITCH LOCK
RIGHT REAR DOOR LOCK MOTOR (4 DOOR)
TAN WIRE
UNLOCK
UNLOCK LOCK
WHT WIRE
