Chevrolet Blazer S15 (1994-1998) window lockout switch Wiring diagrams

1995 VFTC ACCY ALL EXCEPT 2.2L BASE MODELS BRAKE FUSE 12 BRAKE PRESSURE MODULATOR VALVE BRN WIRE BULB TEST CRUISE CONTROL MODULE CRUISE CONTROL SWITCH BRAKE PRESSURE MODULATOR VALVE DRIVER INFORMATION DISPLAY CONTROL MODULE FROM FUSIBLE LINK HTR A/C FUSE 6 HVAC SELECT SWITCH I/P FUSE BLOCK IGNITION SWITCH INSIDE REARVIEW MIRROR LAMP LEFT FRONT WINDOW SWITCH LOCK LOCK OFF NCA WIRE OFF ORG/ WIRE PWR WDO CIRCUIT BREAKER B RADIO RADIO FUSE 11 REAR WINDOW WIPER/ WASHER SWITCH RED WIRE RIGHT FRONT LEFT FRONT WINDOW SWITCH WINDOW SWITCH RUN WIRE TCC/ STOPLAMP SWITCH VEHICLE CONTROL MODULE W/ OVERHEAD CONSOLE W/O OVERHEAD CONSOLE WINDOW LOCKOUT SWITCH WINDSHIELD WIPER MOTOR AND MODULE WINDSHIELD WIPER/ WASHER SWITCH WIPER FUSE 17 YEL WIRE

1995 VFTC BLK WIRE BRN WIRE DK BLU WIRE DK GRN WIRE EXP DN MOD HOT IN RUN I/P FUSE BLOCK (LEFT SIDE OF I/P) LEFT FRONT LEFT FRONT WINDOW MOTOR LEFT FRONT WINDOW SWITCH LEFT REAR LEFT REAR WINDOW MOTOR LEFT REAR WINDOW SWITCH LT BLU WIRE LT GRN WIRE PPL PWR WDO CIRCUIT BREAKER RIGHT FRONT RIGHT FRONT WINDOW MOTOR RIGHT FRONT WINDOW SWITCH RIGHT REAR RIGHT REAR WINDOW MOTOR RIGHT REAR WINDOW SWITCH TAN WIRE UP DN WINDOW LOCKOUT SWITCH YEL WIRE
