Chevrolet Blazer S15 (1994-1998) vss signal-lo Wiring diagram

5 173 PNK WIRE 5 18 PNK PUMP MOTOR RELAY PUMP DRIVER WIRE ANTI-LOCK IND BAT PUMP MOTOR FEED GRD BLK WIRE BLK/WHT WIRE BRAKE IND BRAKE PRESSURE MODULATOR VALVE (LEFT REAR OF ENGINE COMPARTMENT) BRAKE PRESSURE WARNING SWITCH (BRAKE MASTER CYLINDER) BRN WIRE CRUISE CONTROL SYSTEM DIODE MODULE (ABOVE STEERING COLUMN) DK GRN WIRE DK GRN/WHT WIRE FRONT AXLE SWITCH (RIGHT OF DIFFERENTIAL) FUSIBLE LINK GAUGES FUSE 4 HOT AT ALL TIMES HOT IN RUN BRAKE FUSE 12 HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK INSTRUMENT CLUSTER LEFT FRONT WHEEL SPEED SENSOR LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE NCA WIRE ORG/ WIRE PNK WIRE PPL PPL LFT FRT PWM SOL FEED REAR PWM SOL FEED RT FRT PWM SOL FEED PPL PPL PPL REAR ISOLATION SOL FEED PPL/WHT WIRE RED WIRE RIGHT FRONT WHEEL SPEED SENSOR RT FRT ISOLATION SOL FD TAN WIRE TAN/WHT WIRE TCC/STOPLAMP SWITCH (BRAKE PEDAL BRACKET) VEHICLE CONTROL MODULE (RIGHT SIDE OF ENGINE COMPARTMENT) VEHICLE SPEED SENSOR (LEFT SIDE OF TRANS OR REAR OF TRANSFER CASE) VSS SIGNAL-LO WHT WIRE YEL WIRE
