Chevrolet Blazer S15 (1994-1998) vss return wiring diagram
This page shows the only wiring diagram for the component.vss return, which is found in the car Chevrolet Blazer S15 (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
vss return wiring diagram (1 of 1)
4.3L VIN W 2.2L VIN 4
4000 PULSES/MILE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE FUSE 12
BRN WIRE
BRN/WHT (OR PPL) WIRE
BRN/WHT WIRE
CLUTCH PEDAL POSITION SWITCH (CLUTCH PEDAL SUPPORT)
CRUISE CONTROL MODULE
CRUISE STATUS
CRUISE STATUS VEHICLE SPEED INPUT
DK BLU WIRE
DK GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HOT IN RUN
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
LT BLU/BLK WIRE
LT GRN/BLK WIRE
M/T A/T
NCA WIRE
OFF ON
ORG/ WIRE
PPL
PPL A/T PPL PPL M/T
PPL/WHT WIRE
R/A
SET SW DK OFF
STOP/HAZ FUSE 1
TCC STOPLAMP SWITCH (BRAKE PEDAL SUPPORT)
TURN SIGNAL SWITCH
VEHICLE SPEED SENSOR (VSS)
VSS RETURN
VSS SIGNAL
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit -> VSS RETURN
