Chevrolet Blazer S15 (1994-1998) max htr norm vent bi-lv bi-lv Wiring diagram

1995 VFTC A/C CLUTCH DIODE A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY (CENTER REAR OF ENGINE COMPARTMENT) A/C HIGH PRESSURE CUTOUT SWITCH A/C LOW PRESSURE CUTOUT SWITCH A/C ON INPUT BLK WIRE BLK/WHT WIRE BLOWER MOTOR BLOWER MOTOR RELAY (RIGHT REAR OF ENGINE COMPARTMENT) BLOWER RESISTORS (RIGHT REAR OF ENGINE COMPARTMENT) BLOWER SWITCH BRN WIRE CLUTCH CONTROL DEF BLEND DEF BLEND HTR VENT DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE GAUGES FUSE 4 HOT AT ALL TIMES HOT AT ALL TIMES FUSIBLE LINK 2 HOT IN RUN HOT IN RUN, BULB TEST OR START HTR A/C FUSE 6 HVAC CONTROL ASSEMBLY I/P FUSE BLOCK I/P FUSE BLOCK A/C COMP FUSE 14 LT BLU WIRE LT GRN WIRE MAX HTR NORM VENT BI-LV BI-LV MAX NORM MODE SWITCH NCA WIRE OFF ORG/ WIRE PNK WIRE PPL RED WIRE SOLID STATE TAN WIRE TEMPERATURE SELECTOR TEMPERATURE VALVE MOTOR (RIGHT SIDE OF BULKHEAD) VEHICLE CONTROL MODULE (RIGHT SIDE OF ENGINE COMPARTMENT) WHT WIRE
