Chevrolet Blazer S15 (1994-1998) left rear window switch Wiring diagram
This page shows the only wiring diagram for the component.left rear window switch, which is found in the car Chevrolet Blazer S15 (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear window switch (1 of 1)
1995 VFTC
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
EXP DN MOD
HOT IN RUN
I/P FUSE BLOCK (LEFT SIDE OF I/P)
LEFT FRONT
LEFT FRONT WINDOW MOTOR
LEFT FRONT WINDOW SWITCH
LEFT REAR
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LT BLU WIRE
LT GRN WIRE
PPL
PWR WDO CIRCUIT BREAKER
RIGHT FRONT
RIGHT FRONT WINDOW MOTOR
RIGHT FRONT WINDOW SWITCH
RIGHT REAR
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
TAN WIRE
UP DN
WINDOW LOCKOUT SWITCH
YEL WIRE
Go to component -> Power window circuit, 4 door -> LEFT REAR WINDOW SWITCH
